Description
FULL SPECIFICATIONS:
CPU
- Support for Intel® Core™ Ultra Processors (Series 2), LGA1851
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
- Refer to CPU support list for details.
Chipset
Intel® Z890 Chipset
Memory
- 4 x DIMM slots, max. 192GB, DDR5
- Support up to 9200+MT/s (OC), Non-ECC, Un-buffered
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile (XMP) and ASUS Enhanced Memory Profile III (AEMP III)
- NitroPath DRAM Technology
- Refer to memory specifications.
Graphics
- 1 x HDMI™ port (supports max. 8K@60Hz with DSC)
- 2 x Intel® Thunderbolt™ 5 ports (USB Type-C®) supporting DisplayPort and Thunderbolt™ video outputs
- Refer to Intel for graphics specifications updates.
Expansion Slots
- 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes)
- 1 x PCIe 4.0 x4 slot
- Refer to PCIe bifurcation table.
Storage
- Total supports up to 6 x M.2 slots and 4 x SATA 6Gb/s ports
- Support for Intel® Core™ Ultra Processors (Series 2)
- Details on M.2 slots and RAID support included.
Networking
- 1 x Intel® 2.5Gb Ethernet
- 1 x Marvell® AQtion 10Gb Ethernet
- ASUS LANGuard
Wireless & Bluetooth
- Intel® Wi-Fi 7 with 2x2 configuration
- Bluetooth® v5.4
USB Ports
Rear USB (Total 10 ports):
- 2 x Thunderbolt™ 5 ports
- 1 x USB 20Gbps port
- 7 x USB 10Gbps ports
Front USB (Total 10 ports):
- 1 x USB 20Gbps connector
- 1 x USB 10Gbps connector
Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082.
Back Panel I/O Ports
- 2 x Thunderbolt™ 5 USB Type-C® ports
- 1 x USB 20Gbps port
- 1 x HDMI™ port
- 1 x Intel® 2.5Gb Ethernet port
- 1 x Marvell® AQtion 10Gb Ethernet port
- 2 x LED-illuminated audio jacks
- 1 x Optical S/PDIF out port
- 1 x BIOS FlashBack™ button
- 1 x Clear CMOS button
Internal I/O Connectors
Fan and Cooling related:
- 1 x 4-pin CPU Fan header
- 2 x 4-pin Chassis Fan headers
Power related:
- 1 x 24-pin Main Power connector
Storage related:
- 4 x M.2 slots
- 4 x SATA 6Gb/s ports
USB:
- 1 x USB 20Gbps connector
- 1 x USB 10Gbps connector
Special Features
- Extreme OC Kit
- ASUS Q-Design features
- ASUS Thermal Solution
- Aura Sync support
Software Features
ROG Exclusive Software includes:
- ROG CPU-Z
- Dolby Atmos
- Internet Security (1-year)
