Description
Specifications
| GPU | AMD Radeon™ RX 9070 XT |
| Architecture | AMD RDNA™ 4 |
| Engine Clock |
Boost Clock: Up to 3060 MHz Game Clock: Up to 2520 MHz |
| Stream Processors | 4096 |
| Compute Units | 64 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
| Infinity Cache | 64MB |
| Ray Accelerators | 64 |
| AI Accelerators | 128 |
| Memory Size/Bus | 16GB / 256-bit GDDR6 |
| Memory Clock | 20 Gbps Effective |
| Display Support | Maximum 4 Displays |
| Resolution |
HDMI®: 7680×4320 DisplayPort™ 2.1a: 7680×4320 |
| Interface | PCI-Express 5.0 x16 |
| Output |
2x HDMI® 2x DisplayPort™ 2.1a |
| BIOS Support | UEFI |
| Game Index | 4K |
| Sapphire Features |
Quick Connect MagniPlate STEALTH Hidden Power Cable 12V-2x6(H++) External Power Connector Honeywell PTM7950 TIM AeroCurve Fan Blade Free Flow FrameDefense Integrated Cooling Module Cold Rolled Steel Frame Tri-X Cooling Technology High TG Copper PCB Optimized Composite Heatpipes Metal Backplate ARGB Light Bar Fan Quick Connect Two-Ball Bearing Fans Premium 16-Phase Digital Power Design Fuse Protection Intelligent Fan Control Precision Fan Control |
| TriXX Supported Features |
Performance vs. Efficiency Quicksets Glow! Fan Check TriXX Boost External RGB LED MB Synchronization |
| Accessories Bundled |
L-Shape Support Bracket 3-pin 5V ARGB Cable Magnetic Backplate 12V-2x6(H++) to PCI Express 3x8-pin power adapter |
| AMD Features |
AMD HYPR-RX with AFMF 2 AMD FidelityFX™ Super Resolution 4 with AI Upscaling DisplayPort™ 2.1a AMD Radiance Display™ Engine AMD Fluid Motion Frames 2 AMD Radeon™ Anti-Lag 2 AV1 Encode/Decode AMD FidelityFX™ technologies Microsoft® DirectX® 12 Ultimate AMD Noise Suppression AMD FreeSync™ technology AMD Smart Technologies AMD Software: Adrenalin Edition™ |
| Cooler Type |
Tri-X Cooling AeroCurve Fan Blade Free Flow Integrated Cooling Module High TG Copper PCB Optimized Composite Heatpipes Two-Ball Bearing |
| Form Factor | 3.2 slot, ATX |
| Dimensions | 330.8mm (L) x 128.5mm (W) x 65.68mm (H) |
| Power Consumption | 330W Typical Board Power |
| Supported OS | Linux®, Windows® 10, and Windows® 11 (64-bit required) |
| System Requirements |
Minimum 750W Power Supply 12V-2x6(H++) Power Connector (3x8-pin power adapter included) PCI Express® based PC with one X16 lane graphics slot Minimum 8GB of system memory (16GB recommended) |
