Intel i5-10400F 2.90GHz (Comet Lake) Socket LGA1200 Processor

Technical Specification:

Essentials

• Product Collection                   10th Generation Intel® Core™ i5 Processors

• Code Name                            Products formerly Comet Lake

• Vertical Segment                     Desktop

• Processor Number                  i5-10400F

• Status                                     Launched

• Launch Date                            Q2'20

• Lithography                            14 nm

• Use Conditions                       PC/Client/Tablet

• # of Cores                                                                      6

• # of Threads                                                                  12

• Processor Base Frequency                                               2.90 GHz

• Max Turbo Frequency                                                     4.30 GHz

• Cache12 MB Intel®                                                         Smart Cache

• Bus Speed                                                                      8 GT/s

• Intel® Turbo Boost Technology 2.0 Frequency^‡                                    4.30 GHz

• TDP                                                                               65 W


• Embedded Options Available                                          No


• Max Memory Size (dependent on memory type)              128 GB

• Memory Types                                                               DDR4-2666

• Max # of Memory Channels                                            2

• Max Memory Bandwidth                                                 41.6 GB/s

• ECC Memory Supported ^‡                                                                                              No


• Scalability                                                           1S Only

• PCI Express Revision                                            3.0

• PCI Express Configurations ^‡                                                               Up to 1x16, 2x8, 1x8+2x4

• Max # of PCI Express Lanes                                 16


• Sockets Supported                                              FCLGA1200

• Max CPU Configuration                                        1

• Thermal Solution Specification                             PCG 2015C

• T_JUNCTION                                                           100°C

• Package Size                                                      37.5mm x 37.5mm


• Intel® Optane™ Memory Supported ^‡                                                                         Yes

• Intel® Thermal Velocity Boost                                                 No

• Intel® Turbo Boost Max Technology 3.0 ^‡                                No

• Intel® Turbo Boost Technology ^‡                                                                                        2.0

• Intel® vPro™ Platform Eligibility ^‡                                                                                       No

• Intel® Hyper-Threading Technology ^‡                                     Yes

• Intel® Virtualization Technology (VT-x) ^‡                                                                   Yes

• Intel® Virtualization Technology for Directed I/O (VT-d) ^‡                 Yes

• Intel® VT-x with Extended Page Tables (EPT) ^‡                                                 Yes

• Intel® Transactional Synchronization Extensions                      No

• Intel® 64 ^‡                                                                                                                                                       Yes

• Instruction Set                                                                      64-bit

• Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2

• Idle States                                                                           Yes

• Enhanced Intel SpeedStep® Technology                                Yes

• Thermal Monitoring Technologies                                         Yes

• Intel® Identity Protection Technology ^‡                                                                     Yes

• Intel® Stable Image Platform Program (SIPP)                         No


• Intel® AES New Instructions                                                  Yes

• Secure Key                                                                           Yes

• Intel® Software Guard Extensions (Intel® SGX)Yes with Intel® ME

• Intel® OS Guard                                                                  Yes

• Intel® Trusted Execution Technology ^‡                                                                       No

• Execute Disable Bit ^‡                                                                                                                           Yes

• Intel® Boot Guard                                                                Yes
